PCD Cup Wheels
PCD Grinding Disc
Cup Wheel PCD

180mm Sharp Quarter PCD Cup Wheels with 6 Bar Diamond for Concrete Coatings Removal

PCD Grinding Cup Wheels with metal bond diamonds segment are designed to remove coatings over troweled concrete surface and will not damage the concrete floor. The metal bond diamonds arrows segments acts as a stabilizer, depth guide and reduce the gauging of the floor caused by the aggressive PCD segmets and also can protect the PCD Scrapers. Ideal for paint, glue, mastic and epoxy coatings removal.

  • Brand :

    Mosdan
  • Item NO. :

    PCW-03B
  • MOQ :

    5pcs
  • Payment :

    Paypal, T/T
  • Product Origin :

    Xiamen, China
  • Lead Time :

    7-10 days after payment
  • Diameter :

    7''/180mm
  • Arbor :

    22.23, M14, 5/8''-11
  • Locked System :

    Hand Grinders and Walk-behind Grinders
  • PCD Size :

    6x1/4 Sharp PCD Wear 6 Bars

180mm Sharp Quarter PCD Cup Wheels with 6 Bar Diamond for Concrete Coatings Removal



PCD's are manufactured with a Premium Mining Grade Poly Crystalline Diamond that is unmatched in the coating removal industry. This allows PCD'S hold up  under harsh conditions and continue to work when others are worn out.



PCD Grinding Cup Wheels with metal bond diamonds segment are designed to remove coatings over troweled concrete surface and will not damage the concrete floor. The metal bond diamonds arrows segments acts as a stabilizer, depth guide and reduce the gauging of the floor caused by the aggressive PCD segmets and also can protect the PCD Scrapers. Ideal for paint, glue, mastic and epoxy coatings removal.







1 Product Specification



Product Name  180mm Sharp Quarter PCD Cup Wheels with 6 Bar Diamond for Concrete Coatings Removal
Model NO. PCW-03B
Brand  Mosdan
Diameter 7'', also can be made in 4'', 5'', 6''
PCD Size 6x1/4 Sharp PCD Wear 6 Bars
Material  PCD and Diamonds
Arbor Hole  22.23, 5/8''-11, M14
Colors Gold , Blue, Silver, Blue or as customers' request
MOQ 5pcs
Usage Wet or dry use for concrete, terrazzo, mable, granite etc.
Application  Suitable for Hand Grinders and Walk-behind Grinders
Package  Carton box for each piece or as customer's request
Lead time  7-10 days upon receipt of payment for regular orders
Payment Method  T/T, Paypal
Shipping  By sea, by air or by International express, like DHL, UPS, FedEx etc
Certificate  ISO9001, ISO2000, SGS product quality control
Main Market  North America, Australia, European market



2. Features

-Made PCD Scrapers with metal bond segments.

-Concrete PCD grinding cup wheels are ideal for a wide range of coatings removal application

-A great grlue removal tools to remove the coating with silica sand boad cast mixed in.

-Beautiful Package and Short Delivery.

-OEM and ODM are available .



3. Manufacturing Process

Mosdan Metal Bond Diamond Grinding Shoe manufacturing process contains:

3D Diamond Powder mixer, Assebly Mold, Suppression of the cutting tools, Welding segment on the grinding matrix, Spray Paint, Laser Marking , Package.

Mosdan Metal Bond Diamond Grinding Shoe Manufacturing process



4. Packages

Mosdan Diamond Grinding Shoe always packed 1pcs for each box, then boxes packed in the standard exported cartons



5. Payment and Shipment

We support Paypal and T/T (Bank Transfer)

Regular orders, we need about 7-10 days for preparation and production. Normally all the orders not exceed two weeks.

Most likely by Express, we will choose DHL, FedEx, UPS etc, it will take about 5 or 6 days from Xiamen, China to your warehouse .

If bulk orders, we also choose by sea and by air.



6. After-sale Service

Please send us the details resports as feedback if you find our PCD Removal Tools  goods are not in good performance.

We will analize that the possible reasons and try to find a way to solve the problem. If the problem is due to the quality of Mosdan Metal Bond Diamond Grinding Tools product itself, we will make the compensation according to your actual loss and send you new replacement , even some payment refound, but not including the shipping cost.
